Harting Han 3A w/ Harax female/HCC, 3 contacts, 1 - 1.5mm² Part number 09200030745

This is a Harting Han 3A female insert with Harax cage clamp connection, providing three contacts for conductor cross sections of 1 to 1.5 mm². The insert is made of polycarbonate in pebble grey, with silver-plated copper alloy contacts rated at 10 A and suited to a limiting temperature range...
Vendor: Harting
Rubicon Industrial Technology is the exclusive South African distributor for Harting.
Availability: Out Of Stock
Product type: Field Sensing & Connectivity
Please hurry! Only 0 left in stock
Description
Description
x

This is a Harting Han 3A female insert with Harax cage clamp connection, providing three contacts for conductor cross sections of 1 to 1.5 mm². The insert is made of polycarbonate in pebble grey, with silver-plated copper alloy contacts rated at 10 A and suited to a limiting temperature range of -40 to +85 °C. It is intended for field assembly into rectangular connector housings within industrial automation and panel wiring applications.

Key specifications

  • Rated current: 10 A
Specifications
Specifications
x
Limiting Temperature-40 ... +85 °C
Rated Current10 A
Rated Voltageconductor-earth
Conductor Cross-Section1 ... 1.5 mm²
Material InsertPolycarbonate (PC)
Colour InsertRAL 7032 (pebble grey)
Material ContactsCopper alloy
Surface ContactsSilver plated
Packaging Size1
Net Weight43.54 g
Country of OriginRomania
European Customs Tariff Number85366990
GTIN5713140038660
ETIMEC002636
eClass27440114 Rectangular connector (for field assembly)
Rated Impulse Voltage4 kV
Pollution Degree3
Insulation Resistance>1010 Ω
Mating Cycles≥500
Datasheet Name09200030745 Datasheet Harting.pdf
