Harting Han B Protection cover, plastic, single locking lever, 06B

Product Overview

The Han 6 B Plastic Protect Cover (SKU: 09300065410) is a thermoplastic protective accessory designed for bearing pedestal applications with Harting's Han® B series heavy-duty connector systems. This protection cover features a single locking lever mechanism and provides reliable environmental protection with IP65 degree of protection rating.

Key Features:

• Single Locking Lever: Easy installation and removal mechanism
• IP65 Protection: Superior sealing against dust and water ingress
• Wide Temperature Range: Operating temperature from -40°C to +125°C
• Lightweight Design: Only 19g net weight for minimal added bulk
• RoHS Compliant: Environmentally responsible construction
• Made in Germany: Premium quality manufacturing standards

Technical Specifications:

• Article Number: 09 30 006 5410
• Category: Accessories
• Series: Han® B
• Size: 06 B
• Type of Accessory: Protection cover for bearing pedestal
• Material: Thermoplastic
• Locking Type: Single locking lever
• Degree of Protection: IP65 (IEC 60529)
• Operating Temperature: -40°C to +125°C (-40°F to +257°F)
• Net Weight: 19g
• Country of Origin: Germany

Material Properties & Compliance:

• RoHS Compliant: Yes
• ELV Status: Compliant
• China RoHS: e (Exempt)
• REACH Compliant: No restricted substances contained
• California Proposition 65: Contains Nickel

Commercial Information:

• Packaging Size: 1 piece
• European Customs Tariff Number: 85389099
• GTIN: 5713140044241
• eCl@ss: 27440208 Cap for industrial connectors

Applications: Ideal for industrial applications requiring temporary protection of Han 6B connector housings during maintenance, storage, or transport. The bearing pedestal design makes it particularly suitable for rotating equipment and machinery applications where connector protection is critical.

Download existing graphical data for this product:

• Product Data Sheet (PDF)
• Product Declaration Certificate (PDF)
• EPLAN Data Portal - CAD Data & Technical Details
