Balluff BCS R08RR01-PSM80C-EP00,2-GS49 capacitive sensor Part number BCS0055

This is a capacitive proximity sensor designed for flush mounting, with a sensing range of 1 to 8 mm and a PNP normally open switching output. Housed in a PP body measuring 34 x 16 x 8 mm, it operates from 12 to 30 VDC and connects via a 0.20 m M8x1, 3-pin PUR cable with connector. Rated IP67 and suitable for ambient temperatures from -30 to 70°C, it is intended for detecting a range of materials in industrial automation applications, including panel and machine builds where a compact, flush-mountable sensor is required.

Key specifications

• IP rating: IP67
• Operating voltage: 12...30 VDC
• Connection: Cable with connector, M8x1-Male, 3-pin, 0.20 m, PUR
• Output: PNP normally open (NO)
• Operating temperature: -30...70 °C
• Dimensions: 34 x 16 x 8 mm
