Schneider Single Contact Block with body/fixing collar, screw, 1NO + 1NC
Schneider Single Contact Block with body/fixing collar, screw, 1NO + 1NC

Schneider Single Contact Block with body/fixing collar, screw, 1NO + 1NC Part number ZB5AZ105

This contact block is a component of the Harmony XB5 series, providing dual contact functionality with 1 NO + 1 NC, ensuring flexible operation for various control applications.
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: In stock
Product type: Control Panel
Please hurry! Only 6 left in stock
Description
Description
x

This contact block is a component of the Harmony XB5 series, providing dual contact functionality with 1 NO + 1 NC, ensuring flexible operation for various control applications.

Specifications
Specifications
x
Range of productHarmony XB5
Product or component typeComplete body/contact assembly
Device short nameZB5
Fixing collar materialPlastic
Sale per indivisible quantity1
Head typeStandard
Contacts type and composition1 NO + 1 NC
Contact operationSlow-break
Contact block typeSingle
CAD overall width30 mm
CAD overall height42 mm
CAD overall depth32 mm
Terminals description ISO n°1(13-14)NO (11-12)NC
Device compositionFixing collar Body
Contacts usageStandard contacts
Positive openingWith conforming to IEC 60947-5-1 appendix K
Mechanical durability10000000 cycles
Tightening torque0.8…1.2 N.m conforming to IEC 60947-1
Contacts materialSilver alloy (Ag/Ni)
Short-circuit protection10 A cartridge fuse type gG conforming to IEC 60947-5-1
[Ith] conventional free air thermal10 A conforming to IEC 60947-5-1
Documents
Documents
x
Download Datasheet
