Schneider Single contact block, body/fixing collar, 1NO+1NC Part number ZB4BZ105

This single contact block from the Harmony XB4 series features 1 NO + 1 NC contacts with a metal fixing collar. It is designed for screw clamp terminals and provides reliable electrical performance, rated for 10 million mechanical cycles.
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: In stock
Product type: Control Panel
Please hurry! Only 1 left in stock
Description
Description
x
This single contact block from the Harmony XB4 series features 1 NO + 1 NC contacts with a metal fixing collar. It is designed for screw clamp terminals and provides reliable electrical performance, rated for 10 million mechanical cycles.
Specifications
Specifications
x
IP RatingIP20 conforming to IEC 60529
Country of OriginGermany
Compliance/CertificationsCSA / CSA C22.2 No 14 / BV / DNV / GL / IEC 60947-1 / IEC 60947-5-1 / IEC 60947-5-4 / IEC 60947-5-5 / JIS C8201-1 / JIS C8201-5-1 / LROS (Lloyds register of shipping) / UL / UL 508
Temperature: Operating-40°C to 70°C
Part Depth (mm)37mm
Part Width (mm)30mm
Part Height (mm)47mm
Weight (g)62g
Packaging size / unit1 pc(s)
Tightening Torque0.8 - 1.2 Nm
Material: ProductSilver Alloy (contacts) / Zamak
Screw TypeCross compatible with Philips no 1 screwdriver Cross compatible with pozidriv No 1 screwdriver Slotted compatible with flat Ø 4 mm screwdriver Slotted compatible with flat Ø 5.5 mm screwdriver
Connection Style1 NO + 1 NC / (11-12)NC
Connection TypeScrew clamp terminals, <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1 Screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to IEC 60947-1
Current Rating / Rated Current3 A at 240 V / 6 A at 120 V / 0.1 A at 600 V / 0.27 A at 250 V / 0.55 A at 125 V / 1.2 A at 600 V
Operating Period5000000 cycles (Mechanical) / 10000000 cycles, AC-15, 2 A at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C /\n10000000 cycles, AC-15, 3 A at 120 V, operating rate <3600 cyc/h, load factor: 0.5\nconforming to IEC 60947-5-1 appendix C /\n10000000 cycles, AC-15, 4 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5\nconforming to IEC 60947-5-1 appendix C /\n10000000 cycles, DC-13, 0.2 A at 110 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C /\n10000000 cycles, DC-13, 0.5 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5conforming to IEC 60947-5-1 appendix C (Electrical)
Warranty18 Months
