Balluff Inductive standard sensor, PNP, NO, M30, non-flush, M12 4-pin Part number BES01JE

This inductive proximity sensor detects metallic targets at a rated operating distance of 15mm and provides a PNP normally open output switching at up to 100 Hz. The M30x1.5 housing is brass with a nickel-plated finish and a PA 12 sensing face, rated IP68 for use in wet or contaminated industrial environments, and connects via an M12x1, 4-pin male A-coded connector. Being non-flush mount, it requires clearance around the sensing face from surrounding metal and is suited to machine and panel applications operating between 10 and 30 VDC.

Key specifications

• IP rating: IP68
• Operating voltage: 10 - 30 VDC
• Rated voltage: 24 V
• Connection: M12x1 / Male / 4-pin / A-coded
• Output: PNP normally open (NO)
• Mounting: Non-flush mounting
