Balluff Inductive standard sensor, PNP, NO, M5, flush, M8 3-pin Part number BES00L5

This is a compact M5 inductive proximity sensor with a flush-mounting stainless steel housing and PBT sensing face, designed for detecting metal targets at a rated operating distance of 1.5mm. It provides a PNP output via an M8, 3-pin male connector and operates from a 10-30 VDC supply, making it suitable for space-constrained mounting positions on machines and panels. With an IP67 rating and stainless steel construction, it is suited to industrial environments where resistance to dust and moisture ingress is required.

Key specifications

• IP rating: IP67
• Operating voltage: 10 - 30 VDC
• Rated voltage: 24 V
• Connection: M8x1 / Male / 3-pin / M5x0.5
• Output: PNP normally closed (NC)
• Mounting: Flush mounting
