Balluff BES 517-110-RK Inductive limit switch, flush, 2mm Part number BES02MM

This inductive limit switch detects the presence of metal targets without physical contact, providing a sensing range of 2 mm suitable for flush mounting into machine surfaces or panels. The PA 12 housing and IP67 rating allow operation in environments where dust and moisture ingress are a concern, across an ambient temperature range of -25 to 70°C. Typical applications include position and end-of-travel detection on industrial machinery where the sensor face must sit level with surrounding metal without affecting its switching characteristics.

Key specifications

• IP rating: IP67
• Operating temperature: -25...70 °C
• Dimensions: 60 x 11.8 x 63.2 mm
• Material: PA 12
• Mounting: for flush mounting
