Description
xnan
Specifications
x| IP Rating | IP68 |
| Compliance/Certifications | CE UKCA cULus WEEE / IEC 60947-5-2 |
| Material: Housing / Grip | Brass / Nickel-free coated |
| Material: Jacket / Cover Nut | PVC |
| Material: Sensing Surface / Contacts | PBT |
| Cable Length (mm) | 3 000mm |
| Part Diameter (mm) | 18mm |
| Cable Diameter (mm) | 4.5mm |
| Connection Style | Cable, 3.00 m, PVC |
| Tightening Torque | 25 Nm |
| Rated Operating Distance (mm) | 5mm |
| Switching Output | PNP normally open (NO) |
| Switching Frequency (Hz) | 2000 Hz |
| Rated Insulation Voltage | 250 VAC |
| Operating Voltage | 10 - 30 V |
| Rated Voltage | 24 V |
| Rated Operating Current | 200 mA |
