Harting Surface housing, single locking, side entry, 2x M32 Part number 19302160292

Product Overview

The Han 16B-HMC-asg2-LB-M32 is a surface-mounted connector housing from the HMC (High Mating Cycles) series for industrial applications requiring frequent connection/disconnection operations with low construction profile and larger cable capacity. Features aluminum die-cast construction with assembly group 2 design and M32 cable entry for reliable electrical connections in demanding industrial environments with enhanced durability and space optimization.

Key Features

• HMC series surface-mounted housing designed for high mating cycles (≥10,000 cycles)
• Low construction (LB) design with assembly group 2 (asg2) configuration
• Size 16B with single M32 cable entry
• Aluminum die-cast construction, RAL 7037 finish
• Surface mounting for panel and enclosure installation
• IP65 protection, suitable for harsh industrial environments

Technical Specifications

• Housing Size: 16B
• Construction: Low construction (LB) surface mounted HMC series
• Assembly Group: asg2 configuration
• Cable Entry: 1 x M32
• Temperature Range: Industrial operating range per IEC 61984
• Protection: IP65, UL 50/UL 50E type rating
• Material: Aluminum die-cast, powder-coated RAL 7037
• Mating Cycles: ≥10,000 cycles with other HMC components
• Standards: IEC 60529, UL 50/UL 50E

Installation Details

• Surface mounting configuration for panel and enclosure installation
• Low construction design minimizes profile height for space-constrained applications
• Assembly group 2 design for specific mounting requirements
• Single M32 entry accommodates larger cable applications

Applications

• Industrial automation systems requiring frequent connector operation with larger cables
• Machinery and equipment with high connection/disconnection frequency
• Control panels needing extended cycle life with low profile design and M32 capacity
• Applications demanding reliable high-frequency mating operations in compact spaces

Compatibility

• Compatible with Han 16B HMC series inserts and contacts
• Part of Han® HMC connector system
• Surface-mounted housing with low construction for high mating cycles

Environmental Protection

• Protection: IP65 rating against dust and water ingress
• Construction: Corrosion-resistant aluminum die-cast housing
• Durability: ≥10,000 mating cycles with HMC components
• Surface Finish: Powder-coated RAL 7037 (dust grey)

Certifications and Compliance

• Standards: IEC 60529, UL 50/UL 50E
• Certifications: CSA-C22.2 No. 182.3 ECBT8.E235076
• Flammability: V-0 according to UL 94 (locking levers)
• Origin: Germany

Download existing graphical data for this product:

• Product Data Sheet
• Product Declaration Certificate
• EPLAN Data Portal
