Harting Panel feed through housing, double locking, 16B Part number 09300160408

Product Overview

The Han Split Hood 16 B (SKU: 09300160408) is a specialized aluminum die-cast split housing designed for panel feed-through applications. Features two-piece construction for easy installation around existing cables and provides robust connectivity solutions for size 16B applications in industrial environments.

Key Features:

• Split Construction: Two-piece design allows installation around existing cables
• Panel Feed-Through: Designed for through-panel cable routing applications
• Size 16B: Large capacity housing for high-density applications
• Aluminum Die-Cast: Durable construction with powder-coated finish
• NBR Sealing: High-performance nitrile rubber seals for environmental protection
• Easy Installation: Simplified mounting with included M4 screws

Technical Specifications:

• Article Number: 09 30 016 0408
• Category: Hoods/Housings
• Series: Han® B
• Size: 16B
• Type: Split hood for panel feed-through
• Material: Aluminum die-cast, powder-coated
• Sealing Material: NBR (Nitrile Butadiene Rubber)
• Protection Rating: IP65 (IEC 60529)
• Mating Cycles: ≥ 500

Compliance & Certifications:

• RoHS Compliant: Yes
• Material Flammability: UL 94 V-0 rating
• Operating Temperature: -40°C to +125°C
• ELV Status: Compliant
• REACH: No restricted substances
• China RoHS: e (Exempt)
• IEC Standards: IEC 61984 connector compliance

Applications: Ideal for retrofitting existing installations where cables need to pass through panels without disconnection. The split design allows installation around pre-wired cables in industrial machinery, control panels, and automation equipment.

Compatibility: Compatible with Han® B series size 16B inserts. Works with 36 combinable products, 16 accessories, 34 inserts, and various frame options for versatile connectivity solutions.

Download existing graphical data for this product:

• Product Data Sheet (PDF)
• Product Declaration Certificate (PDF)
• EPLAN Data Portal - CAD Data & Technical Details
