Harting Insert, screw, male, black, size 3A, c/s 1.5mm² Part number 09700062616

This Harting insert is a male connector module with six screw-termination contacts, sized 3A with a cross-section of 1.5mm² per contact. Contacts are copper alloy with silver plating, set in a PA insert body, and terminations are made with a tightening torque of 0.25 Nm. Rated at 25 VAC /...
Vendor: Harting
Rubicon Industrial Technology is the exclusive South African distributor for Harting.
Availability: Out Of Stock
Product type: Field Sensing & Connectivity
Please hurry! Only 0 left in stock
Description
Description
x

This Harting insert is a male connector module with six screw-termination contacts, sized 3A with a cross-section of 1.5mm² per contact. Contacts are copper alloy with silver plating, set in a PA insert body, and terminations are made with a tightening torque of 0.25 Nm. Rated at 25 VAC / 60 VDC and 10 A, it is used in modular industrial connector housings for field wiring in automation panels and machinery.

Key specifications

  • Rated voltage: 25 VAC / 60 VDC
  • Connection: Male / 6 contacts
  • Colour: Black
Specifications
Specifications
x
Tariff85366990
GTIN5713140102866
ETIMEC000438
Compliance/CertificationsIEC 60664-1 IEC 61984 / UL 1977 ECBT2.E235076
Material: Sensing Surface / ContactsCopper Alloy / Silver-plated
Material: InsertPA
Packaging Size10 pc(s)
Weight (g)17.9g
Connection TypeMale / 6 contacts
Connection StyleScrew termination
Tightening Torque0.25 Nm
Rated Voltage25 VAC / 60 VDC
Current Rating / Rated Current10 A
ColourBlack
Documents
Documents
x
Download Datasheet
