Harting Insert, monoblock, crimp, male, c/s 0.14 - 4mm² Part number 11056483001

This insert is a monoblock male connector component with 48 crimp-termination contacts, sized for the Han-Yellock 60 series and moulded from PC material with V-0 flammability rating. It accepts conductor cross-sections of 0.14 to 4mm² and is rated at 500V with a current rating of 16A per contact. It is used in industrial connector housings for panel and machine builds requiring multi-pole field wiring connections, with compliance to IEC 60664-1, IEC 61984, UL 1977 and DNV GL standards.

Key specifications

• Rated voltage: 500 V
• Connection: Male / 48 Contacts
• Flammability: V-0
