Harting Insert, crimp, male, size 3A, c/s 0.14 - 2.5mm².

Product Overview

The Han Q 7/0-M is a high-performance male connector insert designed for the HARTING Han® Q series with crimp termination. This compact 7-contact insert with protective earth (PE) features crimp contact termination and is optimized for industrial applications requiring reliable electrical connections with multiple signal paths in space-constrained installations.

Key Features

• Series: Han® Q
• Identification: 7/0
• Gender: Male
• Termination Method: Crimp
• Contacts: 7 + PE (protective earth)
• Conductor Cross-Section: 0.14 - 2.5 mm²
• Rated Current: 10 A
• Rated Voltage: 400 V / 600 V (UL/CSA)
• Size: 3A
• Material: Polycarbonate (PC)
• Color: RAL 7032 (pebble grey)
• Contact Material: Copper alloy, silver plated
• Application: Signal and control connections

Technical Specifications

This male insert is part of the Han® Q series, featuring crimp termination for secure and reliable electrical connections. The insert accommodates conductor cross-sections from 0.14 to 2.5 mm² and is rated for 10A at 400V/600V (UL and CSA). The 7-contact configuration provides multiple signal paths for complex control and automation applications. The crimp connection method provides superior mechanical retention and electrical performance for long-term reliability. The polycarbonate construction ensures excellent durability and environmental resistance. Note: Crimp contacts must be ordered separately.

Compliance & Environmental

• UL and CSA voltage ratings: 400V/600V
• Industrial-grade polycarbonate construction
• Silver-plated contacts for enhanced conductivity
• Size 3A compatibility with Han® Q series
• Rated for 10A current capacity
• Suitable for harsh industrial environments

Applications

Ideal for industrial automation, control systems, and instrumentation applications requiring multiple signal connections in compact installations. Perfect for control panels, measurement equipment, sensor networks, and automation systems where space optimization and reliable multi-signal connectivity are essential. The 7-contact configuration makes it suitable for complex control circuits, data acquisition systems, and multi-channel signal processing applications.
