Harting Connector, solder cup, male, D-sub 5, 5A

Product Overview

The D-SUB IP67 50-pole male solder cup S4 (article no. 09 67 450 5615) is a waterproof industrial connector designed for harsh environment applications. Features solder cup termination with IP67 protection rating, providing complete protection against dust ingress and temporary water immersion for demanding outdoor and industrial installations.

Key Features:

• 50-pole male D-Sub connector (Size: D-Sub 5)
• IP67 waterproof protection rating for harsh environments
• Solder cup termination for permanent wire connections
• S4 specification for enhanced performance
• Thermoplastic resin body with glass-fiber reinforcement
• Brass shell with tin plating for corrosion resistance
• Rated for industrial temperature range

Applications: Outdoor equipment, marine applications, industrial machinery, process control systems, mobile equipment, instrumentation in wet environments, harsh industrial installations.

Technical Specifications:

• Connector Type: Male D-Sub connector
• Contacts: 50 poles (Size: D-Sub 5)
• Termination: Solder cup
• Specification: S4 grade
• Protection Rating: IP67 (IEC 60529)
• Operating Temperature: -25°C to +70°C
• Test Voltage: 1.2 kV (RMS)
• Contact Material: Copper alloy
• Body Material: Thermoplastic resin, glass-fiber filled
• Shell: Brass, tin plated
• Flammability Rating: UL 94 V-0

Environmental Protection:

• IP67 Rating: Complete protection against dust ingress
• Water Protection: Protection against temporary immersion in water
• Corrosion Resistance: Tin-plated brass shell and contacts
• Temperature Range: -25°C to +70°C operating range

Design Features:

• Waterproof Sealing: IP67 protection for wet environments
• Solder Cup Termination: Reliable permanent wire connections
• S4 Specification: Enhanced performance grade
• Reinforced Construction: Glass-fiber filled thermoplastic body
• Corrosion Resistant: Tin-plated brass shell and contacts
• High Contact Density: 50 contacts in compact D-Sub 5 format

Benefits:

• Complete environmental protection for outdoor use
• Reliable solder cup connections for permanent installations
• Robust construction withstands harsh industrial conditions
• High contact density for complex signal applications
• Proven D-Sub form factor for universal compatibility
• UL 94 V-0 flammability rating for safety compliance
• Perfect male counterpart to female IP67 connectors

Standards Compliance:

• DIN 41652: D-Sub connector standard
• CECC 75301-802: Connector specification compliance
• IEC 60529: IP67 protection rating standard
• UL 94 V-0: Flammability rating

Compliance: RoHS compliant, UL 94 V-0 flammability rating, IP67 rated
