Harting Connector socket, D-sub, panel, female, 9-way, 7.5A

Product Overview

The DSUB SV FE TSDC 09P AU2 (article no. 09 67 009 4715) is a standard 9-pole female D-Sub connector featuring solder cup termination and thermoplastic construction. Designed with noble metal over nickel plated contacts for reliable signal transmission in industrial and commercial applications.

Key Features:

• 9-pole female D-Sub connector (Size: D-Sub 1)
• Solder cup termination (TSDC) for secure wire connections
• Noble metal over nickel contact plating for corrosion resistance
• White thermoplastic resin body with glass-fiber reinforcement
• Tin-plated steel shell for electromagnetic shielding
• 7.5A rated current capacity

Applications: Industrial control systems, data communication interfaces, instrumentation connections, automation equipment, computer peripherals, test equipment connections.

Technical Specifications:

• Connector Type: Female D-Sub connector
• Contacts: 9 poles (Size: D-Sub 1)
• Termination: Solder cup (TSDC)
• Rated Current: 7.5A
• Conductor Cross-Section: 0.5 mm² maximum
• Contact Material: Copper alloy
• Contact Plating: Noble metal over nickel (AU2)
• Body Material: Thermoplastic resin, glass-fiber filled (PBTP)
• Shell: Steel, tin plated
• Color: White

Design Features:

• Solder Cup Termination: Reliable wire-to-contact connection
• Reinforced Construction: Glass-fiber filled thermoplastic for durability
• EMI Shielding: Tin-plated steel shell
• Corrosion Resistance: Noble metal contact plating
• Standard D-Sub Size: Compatible with industry-standard applications

Benefits:

• Reliable solder cup connections for permanent installations
• Noble metal plating ensures long-term contact reliability
• Robust thermoplastic construction for demanding environments
• Standard D-Sub form factor for universal compatibility
• High current rating (7.5A) for power and signal applications

Compliance: RoHS compliant, standard D-Sub identification
