Siemens Profinet bundle IM, interface + server + busadapter Part number 6ES7155-6AA01-0BN0

Product Overview

The SIMATIC ET 200SP PROFINET Bundle IM 155-6PN ST delivers comprehensive distributed I/O connectivity for demanding industrial automation applications requiring reliable PROFINET communication. This complete interface module bundle supports up to 32 I/O modules and 16 ET 200AL modules with single hot-swap capabilities, providing seamless integration between PROFINET networks and ET 200SP distributed I/O systems in space-constrained control environments. The bundle includes all essential components for immediate installation and operation.

Key Features

• Complete Bundle Solution: Includes interface module, server module, and BusAdapter for ready-to-install PROFINET connectivity
• IM 155-6PN Standard Interface: Standard PROFINET interface module optimized for ET 200SP systems with reliable communication capabilities
• Single Hot-Swap Technology: Module replacement capability during operation without system shutdown or communication interruption
• High Module Capacity: Supports up to 32 I/O modules and 16 ET 200AL modules for comprehensive system expansion
• Integrated RJ45 Connectivity: Includes BA 2xRJ45 BusAdapter for direct Ethernet connection without additional components
• Compact Design: Space-efficient form factor ideal for installation in compact control boxes with IP20 protection rating
• Advanced Communication: PROFINET IO Device with IRT support, PROFIenergy, and media redundancy capabilities
• Industrial-Grade Reliability: Robust construction for demanding industrial environments with extended operational life

Technical Specifications

• Bundle Type: PROFINET Bundle IM 155-6PN ST | Weight: 0.235 kg
• Module Capacity: Up to 32 I/O modules + 16 ET 200AL modules | Communication: PROFINET IO Device
• Hot-Swap Capability: Single hot-swap supported | Protection Rating: IP20
• Supply Voltage: 19.2-28.8V DC (24V nominal) | Package Dimensions: 10.30 x 12.70 x 6.50 cm
• PROFINET Features: IRT support, PROFIenergy, MRP client | Connectivity: 2x RJ45 Ethernet ports
• Compatibility: TIA Portal V14+, STEP 7 V5.5 SP4+ | Country of Origin: Germany

Bundle Components

• Interface Module (6ES7155-6AU01-0BN0): IM 155-6PN Standard PROFINET interface for ET 200SP communication
• Server Module (6ES7193-6PA00-0AA0): Essential server functionality for system operation and diagnostics
• BusAdapter BA 2xRJ45 (6ES7193-6AR00-0AA0): Dual RJ45 Ethernet connectivity with integrated switch functionality

Replacement Information

Product Phase-Out Notice: This product entered phase-out on October 1, 2024.

Successor Product: 6ES7155-6AA02-0BN0 - SIMATIC ET 200SP, bundle PROFINET interface module IM 155-6 PN ST

• Enhanced Features: Multi hot-swap capability, optional PN strain relief, PN security class 1
• Improved Interface: Enhanced interface module (6ES7155-6AU02-0BN0) with multi hot-swap vs. single hot-swap
• Full Compatibility: Direct bundle replacement with improved capabilities and same component structure

Applications & Integration

Primary Applications:

• Distributed I/O systems requiring complete PROFINET connectivity in manufacturing environments
• Industrial automation systems with space-constrained control cabinets needing ready-to-install solutions
• Process control applications requiring reliable field device connectivity with single hot-swap capability
• Manufacturing systems needing cost-effective, complete PROFINET interface bundles
• Factory automation with standard distributed control architectures requiring immediate deployment

System Compatibility:

• Compatible with SIMATIC S7 controllers via PROFINET IO Device communication
• Integration with TIA Portal V14+ and STEP 7 V5.5 SP4+ engineering environments
• Support for various ET 200SP I/O modules (digital, analog, communication)
• Compatible with ET 200AL modules for extended system functionality
• Seamless integration with existing PROFINET networks and Ethernet infrastructure

Quality & Compliance

• Status: Product Phase-Out (PM400) since October 1, 2024
• Successor: 6ES7155-6AA02-0BN0 | Origin: Germany
• EAN: 4047623408154 | UPC: 804766478055
• RoHS Compliant: Since April 26, 2017 | WEEE: Take-back obligation applicable
• REACH: Contains lead, lead monoxide, silicic acid lead salt, and other substances above 0.1% w/w (safe when used as intended)
• Export Control: AL: N / ECCN: 9N9999
• Standards: Complies with industrial automation and PROFINET communication standards

Package Contents

• 1 × Interface Module (6ES7155-6AU01-0BN0), 1 × Server Module (6ES7193-6PA00-0AA0), 1 × BusAdapter BA 2xRJ45 (6ES7193-6AR00-0AA0), technical documentation, installation accessories
