Siemens Industrial ethernet trailing cable GP 2x2, 4-core, Cat. 5

SKU / Article No. 6XV1870-2D

EAN / Barcode 4019169404198

Product Type Cable & Cable Management

Product Class Data and communication cable

R 113.61

In Stock

View Full Product Details on Siemens 💬 Ask an Expert - Technical Support Available

Product Description

Industrial Ethernet FC TP trailing cable GP 2x2 (PROFINET Type C), TP installation cable for cable carrier applications, 4-core, shielded Cat5e, sold by the meter (3 million bending cycles), delivery unit max. 1000 m, minimum order quantity 20 m. SIMATIC NETCablesSuitable for use in trailing cables, e.g. in the case of continuously moving machine parts.Time is saved thanks to easy and quick on-site installation. Network immune to interference due to double-shielded cables and integrated grounding concept. Silicone-free, therefore suitable for use in the automotive industry (for example on paint lines). Exceeds Category 5 (Cat5e) of the international cabling standards ISO/IEC 11801 and EN 50173. Easy length measurement thanks to printed meter marking.

Permitted cable outer temperature during assembling/handling: -10 °C
Reaction-to-fire according to EN 13501-6: Class: Eca
Category: 5E
Suitable for underground installation: false
Number of cores: 4
Permitted cable outer temperature during assembling/handling: -25 °C
Diameter conductor: 0.75 mm
Permitted cable outer temperature after assembling without vibration: -25 °C
Stranding element: Quad
Core identification: Colour
Min. permitted bending radius, moving application/free movement: 49 mm
Permitted cable outer temperature after assembling without vibration: 75 °C
Screen over stranding: Foil + braiding
Outer diameter approx.: 6.5 mm
NVP value: 69 %
Number of stranding elements: 2
Min. permitted bending radius, stationary application/permanent installation: 49 mm
Min. permitted bending radius, moving application with forced guidance: 49 mm
Conductor surface: Bare
Colour outer sheath: Green
