Siemens LAN cable PVC Cat5e, 2x2x0.32mm² F/ UTP, green, 100m Siemens
📄 Datasheet
Siemens

Siemens LAN cable PVC Cat5e, 2x2x0.32mm² F/ UTP, green, 100m Part number 6XV1840-2AT10

EAN / Barcode 4019169856386
Product Type Cable & Cable Management
Product Class Data and communication cable
ETIM Class Data and communication cable
Back Order
💬 Ask an Expert - Technical Support Available
✓ RoHS Declaration♻ EPD

Product Description

IE FC TP Standard Cable GP 2x2 (PROFINET Type A), CAT5E, bus cable 4-wire, shielded, special configuration for quick assembly to IE FC RJ45 plug 2x2, 100 m. SIMATIC NETCablesIE FC TP Standard Cable GP 2x2 (Type A)For use in automotive industry, in mechanical engineering (robotics and trailing cable applications), in energy automation, in oil and gas production, and in wind turbines.Time is saved thanks to easy and quick on-site installation. Network immune to interference due to double-shielded cables and integrated grounding concept. Silicone-free, therefore suitable for use in the automotive industry (for example on paint lines).

Exceeds Category 5 (Cat5e) of the international cabling standards ISO/IEC 11801 and EN 50173. Easy length measurement thanks to printed meter marking.

Technical Specifications

Bending Radius19.5 - 49
Category5E
ColourGreen / White/ Yellow/ Blue/ Orange
Colour outer sheathGreen
Compliance / CertificationsCE / c(ETL)us / cRUus AWM 21694 AWM I A/B 60°C 600V FT2 / EAC / ROHS Conform / Sun Res
Conductor surfaceBare
Core identificationColour
Diameter conductor0.64 mm
Diameter: External conduit size (mm)6.5mm
Diameter: Internal Conduit Size0.64mm
FlammabilityFlame resistant acc. to UL 1685 (CSA FT 4)
Material: Insulation / Inner sheathPE / PVC
Material: Jacket / Outer SheathPVC
Min. permitted bending radius, moving application with forced guidance49 mm
Min. permitted bending radius, moving application/free movement49 mm
Min. permitted bending radius, stationary application/permanent installation49 mm
Number of cores4
Number of stranding elements2
NVP value69 %
Outer diameter approx.6.5 mm
Peak Operating Voltage80 V
Permitted cable outer temperature after assembling without vibration75 °C
Permitted cable outer temperature during assembling/handling60 °C
Reaction-to-fire according to EN 13501-6: ClassEca
Screen over strandingFoil + braiding
Stranding elementQuad
Temperature: Operating-40°C to 75°C
Weight61000g
Country of OriginGermany
