Siemens 1215C Compact CPU, program/data memory 125KB

Product Overview

The SIMATIC S7-1200 CPU 1215C delivers efficient compact PLC functionality with DC/DC/DC configuration and dual PROFINET ports for versatile automation applications. Featuring comprehensive onboard I/O including 14 digital inputs, 10 transistor outputs rated at 0.5A, and integrated analog capability, this CPU provides reliable control performance with 200 KB program/data memory for mid-range automation tasks requiring efficient transistor-based switching.

Key Features

• Transistor Output Configuration: 14 DI (24V DC) + 10 DO (24V DC transistor 0.5A) + 2 AI (0-10V DC) + 2 AO (0-20mA DC)
• Dual PROFINET Ports: Built-in 2-port PROFINET switch for flexible network topologies and integrated communication
• Efficient Transistor Switching: 0.5A transistor outputs for precise control of electronic loads and interfaces
• Extended Memory Capacity: 200 KB program/data memory for complex automation applications
• Compact Design: High-density I/O integration with transistor outputs in space-efficient form factor
• TIA Portal Integration: Full compatibility with STEP 7 Basic programming environment and TIA Portal ecosystem

Technical Specifications

• CPU Model: CPU 1215C DC/DC/DC | Firmware: V4.6 or higher
• Dimensions: 111mm (W) × 140mm (H) × 85mm (D) | Weight: 0.405 kg
• Power Supply: DC 20.4-28.8V DC | Current Consumption: Standard for CPU plus load requirements
• Digital I/O: 14 DI (24V DC) | 10 DO (24V DC transistor 0.5A switching capacity)
• Analog I/O: 2 AI (0-10V DC) | 2 AO (0-20mA DC)
• Memory: 200 KB program/data memory | Communication: 2×PROFINET ports
• Protection: IP20 | Mounting: DIN rail | Temperature: Industrial operating range

Applications & Integration

Primary Applications:

• Industrial automation requiring precise transistor switching control
• Process control with electronic interface compatibility
• Building automation systems with efficient load switching
• Manufacturing equipment requiring fast switching capabilities
• Electronic control applications with low to medium power requirements

System Compatibility:

• TIA Portal and STEP 7 Basic programming environment (V13 SP1 or higher required)
• PROFINET, Modbus, and various industrial communication protocols
• Expandable with SM 1221/1222/1223 signal modules (up to 8 modules)
• Memory card expansion capability for additional storage
• HMI device connectivity via integrated Ethernet interface

Quality & Compliance

• Status: Active Product (PM300) | Origin: Germany
• EAN: 4047623402756 | UPC: 887621769086
• RoHS Compliant: Since 12.12.2013 | WEEE: Take-back obligation applies
• Export Control: AL: N / ECCN: 9N9999 | Product Class: A (Standard stock item, returnable)
• ATEX: Gas explosion protection category 3G | Protection: IP20
• REACH: Contains lead, lead oxide, 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol, and BPA above 0.1% w/w (safe when used as intended)

Package Contents

• 1 × CPU 1215C DC module (6ES7215-1AG40-0XB0), technical documentation, terminal blocks, mounting hardware
