Siemens

Siemens 1214C Compact CPU, program/data memory 100KB Part number 6ES7214-1BG40-0XB0

EAN / Barcode 4047623402749
Product Type Control Panel
Product Class PLC CPU-module
Category HMI's & PLC's
Sub-category CPU
ETIM Class PLC CPU-module
In Stock
💬 Ask an Expert - Technical Support Available
♻ EPD🌱 EcoTech Profile

Product Description

This compact CPU 1214C is designed for SIMATIC S7-1200 systems, offering 14 digital inputs, 10 relay outputs, and 2 analog inputs. It operates on an AC power supply and provides program and data memory up to 150 KB. The CPU is optimized for small automation systems and features integrated real-time clock functionality and multiple communication protocols.

Technical Specifications

CommunicationRJ45
Compliance/CertificationsCE / CSA / UL / cULus / FM / RCM / KC / Marine approval
Connection TypePG Connections: 4 reserved / 4 max; HMI Connections: 12 reserved / 18 max; S7 Connections: 8 reserved / 14 max; Open User Connections: 8 reserved / 14 max; Web Connections: 2 reserved / 30 max; OPC UA Connections: 0 reserved / 10 max; Total Connections: 34 reserved / 64 max
Current Consumption500 mA - CPU only
Data Transmission Rate100 Mbit/s
Depth75 mm
Explosion safety category for gasATEX gas-ex-protection, Cat. 3G
Height100 mm
IP Rating / DetailedIP20
Memory size150 kByte
ModelCompact
Number of analogue inputs2
Number of digital inputs14
Number of digital outputs10
Number of HW-interfaces industrial Ethernet1
Number of interfaces PROFINET1
Number of relay outputs10
Part Depth (mm)75mm
Part Height (mm)100mm
Part Length (mm)50 000mm - 500 000mm
Part Width (mm)110mm
Processing time (1K, binary operation)0.079999999 ms
Rail mounting possibleYes
Supply Voltage24 VDC
Supply voltage AC 50 Hz85 V
Supply voltage AC 60 Hz85 V
Supporting protocol for ASIYes
Supporting protocol for ModbusYes
Supporting protocol for other bus systemsYes
Supporting protocol for PROFIBUSYes
Supporting protocol for PROFINET IOYes
Supporting protocol for TCP/IPYes
System accessoryYes
Temperature: Operating-20°C to 60°C
Type of memoryRAM
Voltage type (supply voltage)AC
Wall mounting/direct mountingYes
Weight (g)415g
Width110 mm
