Schneider CB basic frame, w/o trip unit, 3-pole, 100A Part number C10F3

This is a 3-pole circuit breaker basic frame rated at 100 A, supplied without a trip unit, for fixed mounting in distribution panels. It is designed for AC systems up to 690 V at 50/60 Hz and carries an IP40 rating for protection against contact and ingress of foreign objects....
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x

This is a 3-pole circuit breaker basic frame rated at 100 A, supplied without a trip unit, for fixed mounting in distribution panels. It is designed for AC systems up to 690 V at 50/60 Hz and carries an IP40 rating for protection against contact and ingress of foreign objects. The frame is suited to operating environments between -25 °C and 70 °C, typical of industrial power distribution boards.

Key specifications

  • IP rating: IP40 conforming to IEC 60529
  • Operating temperature: -25…70 °C
  • Mounting: Fixed
Specifications
Specifications
x
IP Rating / DetailedIP40 conforming to IEC 60529
Compliance/CertificationsEN/IEC 60947-2,UL 60947-4-1
Temperature: Operating-25…70 °C
Max Frequency50/60 Hz
Type of VoltageAC
Rated Operating Voltage690 V AC 50/60 Hz conforming to IEC 60947-2
Mounting TypeFixed
Operating Period(Mech)50000 cycles conforming to IEC 60947-2
Operating Period(Elec)10000 cycles 690 V AC 50/60 Hz In conforming to IEC 60947-2,20000 cycles 690 V AC 50/60 Hz In/2 conforming to IEC 60947-2,30000 cycles 440 V AC 50/60 Hz In conforming to IEC 60947-2,50000 cycles 440 V AC 50/60 Hz In/2 conforming to IEC 60947-2
