Schneider Mini circuit breaker, C, 2-pole, 500VDC, 63A Part number A9N61539

This miniature circuit breaker is a 2-pole device with a C trip curve, rated for a maximum operating voltage of 500 V DC and a current rating of 63A. It provides overcurrent protection in DC circuits and is fixed-mounted within control panels. The device operates within a temperature range of...
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x

This miniature circuit breaker is a 2-pole device with a C trip curve, rated for a maximum operating voltage of 500 V DC and a current rating of 63A. It provides overcurrent protection in DC circuits and is fixed-mounted within control panels. The device operates within a temperature range of -25 to 70°C, suiting installations subject to varying ambient conditions, and complies with EN 60947-2 and IEC 60947-2.

Key specifications

  • Operating temperature: -25…70 °C
  • Colour: White
  • Mounting: Fixed
Specifications
Specifications
x
Compliance/CertificationsEN 60947-2,IEC 60947-2
Temperature: Operating-25…70 °C
Max Frequency50/60 Hz
Type of VoltageDC
Rated Operating Voltage500 V DC
Mounting TypeFixed
Operating Period(Mech)20000 cycles
Operating Period(Elec)3000 cycles L/R = 2 ms
ColourWhite
Documents
Documents
x
Download Datasheet
