Schneider Circuit breaker, 2-pole, 25 kA at 415 VAC, TMD trip unit 16A Schneider Electric
Schneider Circuit breaker, 2-pole, 25 kA at 415 VAC, TMD trip unit 16A Schneider Electric

Schneider Circuit breaker, 2-pole, 25 kA at 415 VAC, TMD trip unit 16A Part number LV438602

This 2-pole circuit breaker is fitted with a TMD trip unit rated at 16 A and provides a breaking capacity of 25 kA at 415 VAC. It is designed for fixed mounting in control panels, with an IP40 rating conforming to IEC 60529 and operation across a temperature range of...
Vendor: Schneider Electric
Availability: In stock
Product type: Control Panel
Please hurry! Only 1 left in stock
Description
Description
x

This 2-pole circuit breaker is fitted with a TMD trip unit rated at 16 A and provides a breaking capacity of 25 kA at 415 VAC. It is designed for fixed mounting in control panels, with an IP40 rating conforming to IEC 60529 and operation across a temperature range of -25 to 70°C. The device accepts both AC and DC voltage types, with a rated operating voltage of 690 V AC at 50/60 Hz, and complies with EN/IEC 60947.

Key specifications

  • IP rating: IP40 conforming to IEC 60529
  • Operating temperature: -25…70 °C
  • Mounting: Fixed
Specifications
Specifications
x
IP Rating / DetailedIP40 conforming to IEC 60529
Compliance/CertificationsEN/IEC 60947
Temperature: Operating-25…70 °C
Max Frequency50/60 Hz
Type of VoltageDC,AC
Rated Operating Voltage690 V AC 50/60 Hz
Mounting TypeFixed
Operating Period(Mech)20000 cycles
Operating Period(Elec)10000 cycles at 277 V In,20000 cycles at 277 V In/2
