Description
xSpecifications
x| IP Rating / Detailed | IP4 |
| Compliance/Certifications | EN/IEC 60669-2-4 |
| Temperature: Operating | -20…50 °C |
| Part Depth (mm) | 70mm |
| Part Width (mm) | 18mm |
| Part Length (mm) | 9mm |
| Part Height (mm) | 77mm |
| Tightening Torque (N.m) | 1.2 Nm |
| Connection Type | Tunnel type terminals - 10 mm² - rigid,Tunnel type terminals - 10 mm² - flexible,Tunnel type terminals - 10 mm² - flexible with ferrule |
| Rated Operating Voltage | 415 V AC 50/60 Hz |
| Mounting Type | Fixed |
| Current Rating | 32 A at 415 V AC 50/60 Hz |
| Operating Period(Mech) | 300000 cycles |
| Operating Period(Elec) | 30000 cycles |
| Colour | White |
