Harting Protective cover for hoods, Double locking lever, size 10B. Part number 19410105406

Product Overview

The Han-Eco Mod.10-C-f. HTE/HSE is a 10-pole contact module from the Han-Eco Modular series for industrial applications requiring versatile connection solutions with female configuration. Features compatibility with both Hood Top Entry (HTE) and Hood Side Entry (HSE) configurations for flexible installation options in demanding industrial environments with cost-effective modular design.

Key Features

• Han-Eco Modular series 10-pole contact module
• Female (f) configuration for versatile connections
• Compatible with both HTE (Hood Top Entry) and HSE (Hood Side Entry)
• 10-pole contact arrangement for multi-circuit applications
• Cost-effective modular design for flexible system configuration
• Enhanced installation flexibility with dual hood compatibility

Technical Specifications

• Series: Han-Eco® Modular
• Module Type: 10-pole contact module, female configuration
• Configuration: Female (f) contacts
• Compatibility: HTE (Hood Top Entry) and HSE (Hood Side Entry)
• Temperature Range: -40°C to +125°C
• Protection: IP65 according to IEC 60529
• Material: High-grade materials with V-0 flammability rating
• Standards: IEC 60529, CSA-C22.2 No. 182.3 ECBT8.E235076

Installation Details

• Modular design allows flexible system configuration
• Female configuration for multi-pole connections
• Compatible with both top entry and side entry hood configurations
• Easy integration into Han-Eco Modular connector systems

Applications

• Industrial automation systems requiring multi-pole connections
• Control systems needing versatile installation options
• Machinery and equipment with flexible mounting requirements
• Applications demanding cost-effective modular design with installation flexibility

Compatibility

• Compatible with Han-Eco Modular connector system
• Part of Han-Eco® Modular series
• Works with both HTE (Hood Top Entry) and HSE (Hood Side Entry) configurations
• Mates with corresponding male 10-pole modules

Environmental Protection

• Temperature: -40°C to +125°C operational range
• Protection: IP65 rating against dust and water ingress
• Durability: Industrial-grade construction for demanding applications
• Flammability: V-0 rating according to UL 94

Certifications and Compliance

• Standards: IEC 60529, CSA-C22.2 No. 182.3 ECBT8.E235076
• Flammability: V-0 according to UL 94
• Safety: Enhanced safety features for industrial applications
• Origin: Germany
