Description
xDimension Ø 12 x 65 mm Style Housing M12x1 Installation quasi-flush Range 8 mm Switching output PNP Normally open (NO)
Specifications
x| dimension | Ø 12 x 65 mm |
| style_housing | M12x1 |
| installation | quasi-flush |
| range | 8 mm |
| switching_output | PNP normally open (NO) |
| switching_frequency | 300 Hz |
| housing_material | Brass, nickel-plated |
| material_sensing | LCP |
| connection | Connector, M12x1-Male, 4-pin |
| operating_voltage | 10...55 VDC |
| ambient_temperature | 0...60 °C |
| ip_rating | IP67 |
| approval_conformity | CEUKCAWEEE |
