Balluff Inductive standard sensor, PNP, NO, M8, flush, M8 3-pin Part number BES00MU

This is an M8 inductive sensor with a flush-mount stainless steel housing, providing a rated operating distance of 1.5mm and a PNP normally open switching output. It operates from 10 to 30 VDC, offers a switching frequency of 5000 Hz, and connects via an M8x1 3-pin male connector. With an IP68 rating and PUR jacket material, it is suited to panel and machine applications where flush mounting in metal is required and space is limited.

Key specifications

• IP rating: IP68
• Operating voltage: 10 - 30 VDC
• Rated voltage: 24 V
• Connection: M8x1 / Male / 3-pin
• Output: PNP normally open (NO)
• Mounting: Flush mounting
