Balluff BES M08MM-PSC40B-BP00,3-GS04 Inductive sensor, PNP, NO Part number BES05U9

This is an inductive proximity sensor with an M8x1 threaded brass housing, designed for quasi-flush installation and a sensing range of 4 mm. It provides a PNP normally open output, operates from 10...30 VDC, and switches at frequencies up to 1200 Hz, with connection via a 0.3 m M12x1 male cable. The IP67 rating and stated ambient temperature range of -25...70 °C suit it to industrial automation and machine-building applications where compact, non-contact position or object detection is required in confined mounting spaces.

Key specifications

• IP rating: IP67
• Operating voltage: 10...30 VDC
• Connection: Cable with connector, M12x1-Male, 3-pin, 0.3 m, PUR
• Output: PNP normally open (NO)
• Operating temperature: -25...70 °C
• Dimensions: Ø 8 x 60 mm
