Balluff BES M08EA-PSC15B-EP00,3-GS26 Discontinued without replacement Part number BES0272

This is an M8 inductive proximity sensor with a stainless steel housing, designed for flush mounting in space-restricted panel and machine applications. It detects targets at a sensing range of 1.5 mm and provides a PNP normally open switching output, operating from 10...30 VDC with a switching frequency of 3000 Hz. The sensor connects via a 0.30 m PUR cable fitted with an M5x0.5 male connector, and its IP67 rating together with an operating range of -25...70 °C suits it to demanding industrial environments. Note: this part is discontinued without replacement.

Key specifications

• IP rating: IP67
• Operating voltage: 10...30 VDC
• Connection: Cable with connector, M5x0.5-Male, 0.30 m, PUR
• Output: PNP normally open (NO)
• Operating temperature: -25...70 °C
• Dimensions: Ø 8 x 10 mm
