Siemens 5 Electronic modules for ET 200S, 4 DO stand, 24VDC, 2A Part number 6ES7132-4BD32-0AA0

Product Overview

The Siemens 6ES7132-4BD32-0AA0 is a digital output module for the SIMATIC ET 200S distributed I/O system, providing 4 standard DC outputs (4 DO) at 24 V DC, each rated for up to 2 A. It is designed for compact, modular distributed control — giving reliable output switching for actuators, relays or other field devices in industrial automation systems, with built-in short-circuit protection, reverse-polarity protection and source-type (PNP) outputs.

Key Features

• Digital output module (4 DO) for SIMATIC ET 200S distributed I/O system
• 4 outputs, each DC 24 V, 2 A (standard output configuration)
• Source-type transistor outputs (PNP, current-sourcing)
• Reverse polarity protection when using same load voltage as power module
• Short-circuit protection for all outputs (typical response threshold 2.8 … 7.2 A)
• Compact width: 15 mm — saves space in control cabinet / I/O rack
• Address space per module: 1 byte (plus status byte for QI if used)
• Typical power loss: 1.6 W under standard load (all outputs ON)
• Fast output switching: output delay (0 → 1) typ. 45 µs / max. 50 µs, output delay (1 → 0) typ. 90 µs / max. 120 µs
• Typical operation supports lamp load up to 10 W, load resistance range: 12 Ω … 3400 Ω

Technical Specifications

• Article Number: 6ES7132-4BD32-0AA0
• Module Type: ET 200S digital output module, 4 DO standard
• Number of Outputs: 4
• Output Voltage (DC): 24 V DC (from ET 200S power module)
• Output Current per Channel: 2 A (max)
• Output Type: Source outputs (PNP, current-sourcing)
• Output Protection: Short-circuit protection; output shutdown threshold typical 2.8 … 7.2 A
• Reverse-Polarity Protection: Yes (when using correct load-voltage supply)
• Address Space: 1 byte per module (plus QI status byte if enabled)
• Power Loss (typical): 1.6 W (all outputs loaded)
• Module Width: 15 mm — compact form factor
• Switching Speed (typical): 0→1: ~45 µs; 1→0: ~90 µs
• Load Types Supported: Resistive, inductive loads and lamp loads (up to 10 W per channel)
• Load Resistance Range: 12 Ω … 3400 Ω
• Supply Voltage Range: 24 V DC (via ET 200S power module) — within specification limits
• Compatibility: SIMATIC ET 200S distributed I/O system; backplane & bus communication via ET 200S base module / interface
• Environmental / Mounting: DIN-rail or module-rack mounting within ET 200S, industrial control cabinet context

Compliance & System Integration

• Part of the Siemens SIMATIC ET 200S distributed I/O system family — modular digital output modules
• Designed according to Siemens industrial standards for reliability and safety
• Suitable for global industrial automation deployments, machine control, distributed I/O installations, and modular control cabinets

Applications

The 6ES7132-4BD32-0AA0 module is used for switching and controlling field actuators, relays, valves, solenoids, indicator lamps or other DC loads in distributed I/O architectures. It is ideal for machine automation, process control, remote I/O racks, control panels and modular automation systems where compact, reliable, and protected digital outputs are needed — especially in environments requiring 24 V DC control signals and flexible wiring. Its short-circuit protection and compact size make it suitable for dense I/O layouts and industrial applications.
