Schneider Pushbutton, plastic, flush, red, 1NC Part number XA2EA42

The red flush push-button from the Easy Harmony XA2 series features 1NC contact, spring-return mechanism, and a plastic bezel. It is suitable for 22 mm mounting and offers a mechanical durability of up to 1.5 million cycles, providing reliable control in industrial applications.
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x
The red flush push-button from the Easy Harmony XA2 series features 1NC contact, spring-return mechanism, and a plastic bezel. It is suitable for 22 mm mounting and offers a mechanical durability of up to 1.5 million cycles, providing reliable control in industrial applications.
Specifications
Specifications
x
IP RatingIP65 conforming to IEC 60529
Country of OriginGermany
Compliance/CertificationsCCC / CE / GB 14048.1 / GB 14048.5 / IEC 60947-1 / IEC 60947-5-1
Temperature: Operating-25°C to 55 °C
Part Depth (mm)54.7mm
Part Width (mm)30mm
Part Height (mm)42mm
Diameter (mm)22.5mm
Weight (g)32g
Packaging size / unit1 pc(s)
Tightening Torque0.8 Nm
Material: ProductPlastic
Connection Style1 NC
Connection TypeScrew clamp terminal, <= 2 x 1.5 mm² Screw clamp terminal, <= 1 x 2.5 mm² Screw clamp terminal, >= 1 x 0.5 mm² Faston terminals, connection size: 6.3 mm
Current Rating / Rated Current3 A at 240 V, AC-15, A600 0.27 A at 250 V, DC-13, Q600
Operating Period1500000 cycles (Mechanical) / 500000 cycles, AC-15, 3 A at 230 V, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC 60947-5-4 / 500000 cycles, DC-13, 0.2 A at 110 V, operating rate <60 cyc/mn, load factor: 0.5 (Electrical)
ColourBlack / Red
