Schneider Inductive sensor, brass, M18, 12 - 24VDC, 2m Part number XS218BLPAL2

This inductive sensor detects the presence of metallic targets without physical contact, making it suitable for position and object detection tasks on automated machinery. Housed in a brass M18 body, it operates on a 12–24VDC supply and is supplied with a 2m cable for direct connection into control circuits. Typical...
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Field Sensing & Connectivity
Please hurry! Only 0 left in stock
Description
Description
x

This inductive sensor detects the presence of metallic targets without physical contact, making it suitable for position and object detection tasks on automated machinery. Housed in a brass M18 body, it operates on a 12–24VDC supply and is supplied with a 2m cable for direct connection into control circuits. Typical applications include machine building and panel-level automation where compact, threaded-body sensors are required for mounting in confined spaces.

Specifications
Specifications
x
Productdatasheet
Range of productTelemecanique Inductive proximity sensors XS
Series nameGeneral purpose
Sensor typeInductive proximity sensor
Sensor nameXS2
Sensor designCylindrical M18
Size53 mm
Body typeFixed
Enclosure materialNickel plated brass
Type of output signalDiscrete
Wiring technique3-wire
[Sn] nominal sensing distance8 mm
Discrete output function1 NO
Discrete output typePNP
Electrical connectionCable
Cable length2 m
[Us] rated supply voltage12...24 V DC with reverse polarity protection
Switching capacity in mA<= 200 mA with overload and short-circuit protection
IP degree of protectionIP67 conforming to IEC 60529
ISO threadM18 x 1
Detection faceFrontal
Detector flush mountingNon flush mountable
MaterialMetal
Front materialPBT
Operating zone0…6.4 mm
Differential travel1...15% of Sr
Output circuit typeDC
23 May, 20221
Cable composition3 x 0.14 mm²
Wire insulation materialPVC
Status LEDOutput state: 1 LED (yellow)
Supply voltage limits10…36 V DC
Switching frequency<= 500 Hz
Maximum voltage drop<2 V (closed)
Current consumption<= 10 mA no-load
Maximum delay first up15 ms
Maximum delay response0.1 ms
Maximum delay recovery1 ms
MarkingCE
Threaded length33 mm
Length53 mm
Net weight0.105 kg
Product certificationsCSA UL
Ambient air temperaturefor -25…70 °C
Vibration resistance25 gn amplitude = +/- 2 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
Shock resistance50 gn for 11 ms conforming to IEC 60068-2-27
Unit Type of Package 1PCE
Number of Units in Package1 1
Package 1 Weight96.0 g
Package 1 Height2.5 cm
Package 1 width11.3 cm
Package 1 Length15.4 cm
Unit Type of Package 2S02
Package 2 Weight3.978 kg
Package 2 Height15 cm
Package 2 width30 cm
Package 2 Length40 cm
