Schneider Inductive proximity sensor, fixed, 20mm range Part number XS8C4A1MPG13

This sensor detects the presence of metallic objects without physical contact, switching output when a target enters its fixed 20mm sensing range. It is designed for fixed installation on machinery and panels where reliable position or presence detection of metal parts is required. Typical applications include automation and process equipment...
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Field Sensing & Connectivity
Please hurry! Only 0 left in stock
Description
Description
x

This sensor detects the presence of metallic objects without physical contact, switching output when a target enters its fixed 20mm sensing range. It is designed for fixed installation on machinery and panels where reliable position or presence detection of metal parts is required. Typical applications include automation and process equipment where inductive sensing offers a non-contact alternative to mechanical limit switches.

Specifications
Specifications
x
Product data sheetXS8C4A1MPG13
Detection face5 positions turret head
Front materialPBT
Operating zone0…16 mm
Differential travel3...15% of Sr
Repeat accuracy<= 3% of Sr
Cable entry number1 tapped entry for Pg 13.5 cable gland
Status LEDSupply on: 1 LED (green) Output state: 1 LED (yellow)
Supply voltage limits20…264 V AC/DC
Maximum residual current1.5 MA open state 120 V 0.6 mA open state 24 V
Switching frequency<= 25 Hz AC <= 50 Hz DC
Maximum voltage drop<5.5 V (closed)
Maximum delay first up7.5 ms
Maximum delay response1.2 ms
Maximum delay recovery1.8 ms
MarkingCE
Height40 mm
Length40 mm
17 Dec, 20241
Width117 mm
Net weight0.244 kg
Product certificationsUL[RETURN]CCC[RETURN]CSA
Ambient air temperature for operation-25…70 °C
Ambient air temperature for storage-40…85 °C
Vibration resistance25 gn amplitude = +/- 2 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
Shock resistance50 gn for 11 ms conforming to IEC 60068-2-27
Packaging without single use plasticNo
Packaging made with recycledcardboard No
SCIP Number75d611ba-692a-4e35-ab64-a65a95931047
EU RoHS DirectivePro-active compliance (Product out of EU RoHS legal scope)
Mercury freeYes
RoHS exemption informationYes
Circularity ProfileNo need of specific recycling operations
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height4.200 cm
Package 1 Width4.400 cm
Package 1 Length14.000 cm
Package 1 Weight245.000 g
Unit Type of Package 2S02
Number of Units in Package 228
Package 2 Height15.000 cm
Package 2 Width30.000 cm
Package 2 Length40.000 cm
Package 2 Weight7.333 kg
Documents
Documents
x
Download Datasheet
