Siemens Power contactor, size S00, 3-pole, 230VAC, 5.5kW
View on Siemens 📄 Datasheet
Siemens

Siemens Power contactor, size S00, 3-pole, 230VAC, 5.5kW Part number 3RT2017-1AP02

EAN / Barcode 4011209784994
Product Type Control Panel
Product Class Power contactor, AC switching
ETIM Class Power contactor, AC switching
Back Order
View Full Product Details on Siemens 💬 Ask an Expert - Technical Support Available
♻ EPD

Product Description

Power Contactor

The SIRIUS 3RT2 power contactor is designed for switching motors with high contact reliability in a compact design.

Technical details:

  • Type: AC-3e/AC-3
  • Current: 12 A
  • Power: 5.5 kW / 400 V
  • Poles: 3-pole
  • Control Voltage: 230 V AC
  • Frequency: 50/60 Hz
  • Auxiliary Contacts: 1 NC
  • Terminal Type: Screw terminal
  • Size: S00
  • Standards: IEC and UL/CSA
  • Ready for IE3/IE4

Customer benefits:

  • Part of the modular SIRIUS system with optimally coordinated products.
  • Can be combined with a variety of other components in the load feeder.
  • Factory tested device combinations.
  • Best connection to automation level for every application (parallel, via ASi or IO-Link).
  • Integrated auxiliary switches reduce design complexity.
  • Front-panel terminals simplify wiring.
  • Climate-resistant and approved for worldwide use.
  • Available with spring-type terminals for fast, maintenance-free and vibration-proof connection.
  • Comprehensive range of standardized accessories for all sizes.
  • Link modules and function modules reduce wiring expense.
  • Efficient and up to date with the SIRIUS modular system.

Technical Specifications

Depth73 mm
Height58 mm
Modular versionYes
Number of auxiliary contacts as normally closed contact1
Number of normally open contacts as main contact3
Operating voltage AC 50 Hz690 V
Operating voltage AC 60 Hz690 V
Rated control supply voltage AC 50 Hz230 V
Rated control supply voltage AC 60 Hz230 V
Rated operation current Ie at AC-1, 400 V22 A
Rated operation current Ie at AC-3, 400 V12 A
Rated operation current Ie at AC-4, 400 V8.5 A
Rated operation power at AC-3, 400 V5.5 kW
Rated operation power NEMA5.8839904 kW
Type of electrical connection of main circuitScrew connection
Voltage type for actuatingAC
Width45 mm
Part Width50 mmmm
Part Height61 mmmm
Part Depth77 mmmm
Weight233 gg
Country of OriginGermany
View complete specifications on Siemens
