Schneider Pressure sensor, adjustable scale, 1c/o, 300 bar Part number XMLB300D2S11

This pressure sensor monitors fluid or pneumatic pressure and switches an output when the level crosses a set point on its adjustable scale, up to 300 bar. It is fitted with a single changeover contact (1c/o), allowing it to signal both rising and falling pressure conditions to a controller or...
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Field Sensing & Connectivity
Please hurry! Only 0 left in stock
Description
Description
x

This pressure sensor monitors fluid or pneumatic pressure and switches an output when the level crosses a set point on its adjustable scale, up to 300 bar. It is fitted with a single changeover contact (1c/o), allowing it to signal both rising and falling pressure conditions to a controller or indicator. Typical applications include hydraulic and pneumatic circuits within industrial machinery and panels where pressure thresholds need to be monitored and acted upon.

Specifications
Specifications
x
Product data sheetXMLB300D2S11
Possible differential minimumat low setting 19.4 bar (- 1.5 bar, + 1.7 bar)
Maximum permissible pressure- per cycle 375 bar
Terminal block type4 terminals
Operating rate<= 60 cyc/mn at > 0 °C
Repeat accuracy< 2 %
[Ui] rated insulation voltage300 V conforming to CSA C22-2 No 14 300 V conforming to UL 508 500 V conforming to EN/IEC 60947-1
[Uimp] rated impulse withstandvoltage 6 kV conforming to EN/IEC 60947-1
Auxiliary contacts operationSnap action
Jul 22, 20111
Contacts materialSilver contacts
Resistance across terminals< 25 mOhm conforming to IEC 255-7 category 3 < 25 mOhm conforming to NF C 93-050 method A
Short circuit protection10 A cartridge fuse type gG (gl)
Mechanical durability3000000 cycles
SettingExternal
Terminals description ISO n°1(13-14-11-12)OF
Height75 mm
Depth113 mm
Width35 mm
CAD overall depth75 mm
CAD overall height113 mm
CAD overall width35 mm
Product weight0.75 kg
StandardsCE CSA C22-2 No 14 EN/IEC 60947-5-1 UL 508
Product certificationsBV CCC CSA DNV (Det Norske Veritas) GL LROS (Lloyds register of shipping) RINA UL VIT-SEPRO
Protective treatmentTC
Ambient air temperature for operation-25...70 °C
Ambient air temperature for storage-40...70 °C
Operating positionAny position
Vibration resistance4 gn (f = 30...500 Hz) conforming to IEC 68-2-6
Shock resistance50 gn conforming to IEC 68-2-27
Class of protection against electricshock Class I conforming to IEC 1140 Class I conforming to IEC 536 Class I conforming to NF C 20-030
IP degree of protectionIP66 conforming to EN/IEC 60529
Documents
Documents
x
Download Datasheet
