Schneider XCKS Limit switch, thermoplastic, 1NC+1NO, M20
Schneider XCKS Limit switch, thermoplastic, 1NC+1NO, M20

Schneider XCKS Limit switch, thermoplastic, 1NC+1NO, M20 Part number XCKS141H29

This limit switch uses a thermoplastic body and features a 1NC+1NO contact configuration with an M20 cable entry. It detects the position or presence of moving machine parts and signals this via its switched contacts to a control circuit. Typical applications include machine guarding and end-of-travel detection on industrial equipment...
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Field Sensing & Connectivity
Please hurry! Only 0 left in stock
Description
Description
x

This limit switch uses a thermoplastic body and features a 1NC+1NO contact configuration with an M20 cable entry. It detects the position or presence of moving machine parts and signals this via its switched contacts to a control circuit. Typical applications include machine guarding and end-of-travel detection on industrial equipment and automation panels.

Specifications
Specifications
x
Product datasheetxcks141h29
Switch actuationBy 30° cam
Contacts insulation formZb
Number of steps1
Positive openingWithout
Minimum torque for tripping0.15 N.m
Minimum actuation speed0.01 m/min
Maximum actuation speed1.5 m/s
[Ithe] conventional enclosedthermal current 10 A AC
[Ui] rated insulation voltage500 V degree of pollution 3 conforming to IEC 60947-1 300 V conforming to UL 508 300 V conforming to CSA C22.2 No 14
Resistance across terminals<= 25 MOhm conforming to IEC 60255-7 category 3
[Uimp] rated impulse withstandvoltage 6 kV conforming to IEC 60664 6 kV conforming to IEC 60947-1
Short circuit protection10 A by gG cartridge fuse
Mechanical durability20000000 cycles
Width40 mm
Height73 mm 1 / 2
Depth36 mm
Product weight0.155 kg
Terminals description ISO n°1(13-14)NO (21-22)NC
Shock resistance50 gn (duration = 11 ms) conforming to IEC 60068-2-27
Vibration resistance(f = 10...500 Hz) conforming to IEC 60068-2-6
IP degree of protectionIP65 conforming to IEC 60529
IK degree of protectionIK03 conforming to EN 50102
Class of protection against electricshock Class II conforming to IEC 61140 Class II conforming to NF C 20-030
Ambient air temperature foroperation -25...70 °C
Protective treatmentTC
Product certificationsCCC CSA UL
StandardsCENELEC EN 50041 EN 60204-1 EN 60947-5-1 IEC 60204-1 IEC 60947-5-1 UL 508 CSA C22.2 No 14
Documents
Documents
x
Download Datasheet
