Schneider Pilot light, metal, LED, orange, 24VAC/DC Part number XB4BVB5

This blue flush-mounted push-button provides reliable operation with a plain lens and spring return mechanism. It includes screw clamp terminals and complies with IEC standards for industrial environments.
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: In stock
Product type: Control Panel
Please hurry! Only 2 left in stock
Description
Description
x
This blue flush-mounted push-button provides reliable operation with a plain lens and spring return mechanism. It includes screw clamp terminals and complies with IEC standards for industrial environments.
Specifications
Specifications
x
IP RatingIP66 / IP67 / IP69 / IP69K
Compliance/CertificationsCSA / CSA C22.2 No 14 / IEC 60947-1 / IEC 60947-5-1 / IEC 60947-5-4 / IEC 60947-5-5 / JIS C8201-1 / JIS C8201-5-1 / UL 508 / UL Listed
Temperature: Operating-40°C to 70 °C
Part Depth (mm)54mm
Part Width (mm)30mm
Part Height (mm)47mm
Weight (g)80g
Packaging size / unit1 / 150 / 1200 pc(s)
Connection TypeScrew clamp terminals / <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1 / Screw clamp terminals / 1 x 0.22 - 2 x 2.5 mm² without cable end conforming to IEC 60947-1
Supply Voltage24 VAC/DC 50/60 Hz
Current Consumption18 mA
Warranty18 Months
ColourOrange
Documents
Documents
x
Download Datasheet
