Description
xiC60N circuit breakers are multi-standard circuit breakers which protect against short-circuit and overload currents. Functional unit Protect during 20 years the installation against overloads and short-circuits in circuit with assigned voltage 500 V and rated current 40 A. This protection is ensured in accordance with 4-poles, 4500A rated breaking capacity and curve code C
Specifications
x| IP Rating / Detailed | IP20 B conforming to EN/IEC 60529 |
| Compliance/Certifications | EN 60898-1,IEC 60898-1,EN 60947-2,IEC 60947-2 |
| Temperature: Operating | -35…70 °C |
| Part Depth (mm) | 78.5mm |
| Part Width (mm) | 72mm |
| Part Length (mm) | 14mm |
| Tightening Torque (N.m) | 3.5 Nm |
| Connection Type | Single terminal (top or bottom) 1…35 mm² rigid,Single terminal (top or bottom) 1…25 mm² flexible |
| Max Frequency | 50/60 Hz |
| Type of Voltage | AC |
| Mounting Type | Removable comb busbar installed |
| Colour | White |
