Schneider Circuit breaker, TMD trip unit, 25kA @ 415VAC, 3-pole, 250A
Schneider Circuit breaker, TMD trip unit, 25kA @ 415VAC, 3-pole, 250A

Schneider Circuit breaker, TMD trip unit, 25kA @ 415VAC, 3-pole, 250A Part number C25B3TM250

This Schneider Electric product is a circuit breaker. The housing is rated IP40 conforming to IEC 60529 and the unit is specified for -25…70 °C.Key specifications IP rating: IP40 conforming to IEC 60529 Operating temperature: -25…70 °C Mounting: Fixed
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x

This Schneider Electric product is a circuit breaker. The housing is rated IP40 conforming to IEC 60529 and the unit is specified for -25…70 °C.

Key specifications

  • IP rating: IP40 conforming to IEC 60529
  • Operating temperature: -25…70 °C
  • Mounting: Fixed
Specifications
Specifications
x
IP Rating / DetailedIP40 conforming to IEC 60529
Compliance/CertificationsEN/IEC 60947-2
Temperature: Operating-25…70 °C
Weight (g)2400.0g
Max Frequency50/60 Hz
Type of VoltageAC
Rated Operating Voltage690 V AC 50/60 Hz
Mounting TypeFixed
Operating Period(Mech)20000 cycles
Operating Period(Elec)20000 cycles at 440 V In/2,10000 cycles at 440 V In,10000 cycles at 690 V In/2,5000 cycles at 690 V In
