Schneider Limit switch, snap, M20, 1NC + 1NO
Schneider Limit switch, snap, M20, 1NC + 1NO

Schneider Limit switch, snap, M20, 1NC + 1NO Part number XCKJ10541H29

This limit switch features a plastic roller lever with variable length actuation and a snap-action mechanism providing 1NC+1NO contacts. The housing is constructed from thermoplastic material with an M20 x 1.5 cable entry and carries an IP66 protection rating conforming to IEC 60529. It is rated for operation across an...
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x

This limit switch features a plastic roller lever with variable length actuation and a snap-action mechanism providing 1NC+1NO contacts. The housing is constructed from thermoplastic material with an M20 x 1.5 cable entry and carries an IP66 protection rating conforming to IEC 60529. It is rated for operation across an ambient temperature range of -25°C to +70°C, suiting applications where position or presence detection is required within control panels and automated machinery.

Key specifications

  • Material: Thermoplastic Housing
Specifications
Specifications
x

Product Name

LabelLimit Switch XC Standard, XCKJ, Thermoplastic Plastic Roller Lever Variable Length, 1NC+1NO, Snap, M20

Product Details

Product ReferenceXCKJ10541H29
Switch ActuatorPlastic Roller Lever - Variable Length
Contacts1 Normally Closed (NC) + 1 Normally Open (NO)
Contact OperationSnap Action
MaterialThermoplastic Housing
Cable EntryM20 x 1.5

Environmental Data

Protection RatingIP66 conforming to IEC 60529
Ambient Air Temperature for Operation-25 °C to +70 °C
Net Zero CommitmentSchneider Electric aims to achieve Net Zero status by 2050

Sustainability

InitiativesUse Better, Use Longer, Use Again (Circularity & Sustainability Campaign)
Documents
Documents
x
Download Datasheet
