Schneider Limit switch, metal enclosure, 2 c/o, 2-pole

This limit switch from the OsiSense XC range features a metal enclosure with a rotary head operator and a spring return roller lever in zinc plated steel, actuated by lateral approach from two directions. It provides 2 c/o contacts across 2 poles, with snap action operation and a tripping angle...

Vendor: Schneider Electric

Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.

Availability: Out Of Stock

Product type: Field Sensing & Connectivity

Please hurry! Only 0 left in stock

Description
Specifications
Documents
Alternatives

OsiSense XC Special limit switch XCRT - metal enclosure zinc plated steel roller with lever - 2C/O

Name: Schneider Limit switch, metal enclosure, 2 c/o, 2-pole
Brand: Schneider Electric
SKU: XCRT115

Product Information

Product Code: XCRT115

Product Details

Weight (in Kg)	1.286
Net weight	1.17 kg
Product Or Component Type	limit switch
Ambient air temperature for operation	-25 to 70 °C
Length	75 mm
Contact Operation	snap action
Mechanical Durability	300000 cycles
Positive Opening	without
Protective Treatment	TC
Short-circuit Protection	10 A cartridge fuse, type gG
Type Of Operator	spring return roller zinc plated steel with lever
Series Name	special format
Head Type	rotary head
Number Of Poles	2
Material	metal
IP Degree of Protection	IP65 conforming to IEC 60529
Body Material	zinc alloy
Contact Block Per Direction	2 per direction
Contacts Insulation Form	Za
Contacts Type and Composition	2 C/O
Minimum Actuation Speed	0.01 m/min
Minimum Torque For Tripping	1 N.m
Movement of Operating Head	rotary
Number of Steps	2
Switch Actuation	by conveyor belt
Tripping angle	10 ° for fault signalling, 18 ° for stopping of the conveyor belt
Type of approach	lateral approach, 2 directions
Standards	EN 60947-5-1, NF C 79-130, CSA C22.2 No 14, IEC 60947-5-1, IEC 60204-1, EN 60204-1
Electrical Durability	5000000 cycles, DC-13, inductive load type, 120 V, 4 W, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
Rated impulse withstand voltage	6 kV conforming to IEC 60664, 6 kV conforming to IEC 60947-1
Contact code designation	A300, AC-15 (Ue = 240 V), Ie = 3 A conforming to EN/IEC 60947-5-1 appendix A
Terminals Description	(11-12)NC, (13-14)NO
Rated Insulation Voltage	300 V conforming to UL 508, 500 V (pollution degree 3) conforming to IEC 60947-1
Overvoltage Category	class I conforming to IEC 61140, class I conforming to NF C 20-030
Maximum Displacement Angle	-90 °, 90 °
Ambient air temperature for storage	-40 to 70 °C
Compatibility code	XCRT
Depth	75 mm
Device short name	XCRT
Fixing Mode	by the body
Height	95 mm
Range of Product	OsiSense XC
Shock Resistance	30 gn for 18 ms conforming to IEC 60068-2-27
Vibration Resistance	9 gn (f= 10-500 Hz) conforming to IEC 60068-2-6
Width	85 mm
Cable entry	1 entry tapped for Pg 13.5 cable gland, cable outer diameter: 9-12 mm conforming to NF C 68-300
Electrical Connection	screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm²
Maximum Resistance Across Terminals	25 MOhm conforming to IEC 60255-7 category 3
Product Specific Application	for conveyor belt shift monitoring
Body Type	fixed
