Murr Miro 6.2 Opto-coupler, screw, triac 1A, 53VDC

Product Overview

The Murrelektronik MIRO 6.2 24VDC-250VAC/1A is a compact triac-based optocoupler module designed for DC-to-AC switching applications requiring electrical isolation. This ultra-compact 6.2mm width module provides reliable AC switching capability up to 1A at 250VAC output, controlled by DC input signals up to 53VDC. The device features secure screw terminal connections and is ideal for controlling AC loads from DC control systems in space-constrained control cabinet installations.

Key Features

• Ultra-compact 6.2mm width design for maximum space efficiency
• Triac-based optocoupler for DC-to-AC switching
• High AC switching capacity: 1A at 250VAC output
• DC control input: up to 53VDC maximum
• 24VDC nominal operation for industrial control systems
• Galvanic isolation between DC input and AC output
• Screw terminal connections for secure wiring
• Zero-crossing switching for reduced electrical interference

Technical Specifications

• Model: MIRO 6.2 24VDC-250VAC/1A Optocoupler Module
• Article Number: 52571
• Input Voltage: 53VDC maximum
• Output Voltage: 250VAC maximum
• Output Current: 1A continuous
• Control Voltage: 24VDC nominal
• Module Width: 6.2mm
• Connection Type: Screw terminals
• Switching Element: Photo-triac

Electrical Characteristics

• Control Input: 24VDC nominal, 53VDC maximum
• AC Load Switching: 250VAC maximum, 1A continuous
• Switching Technology: Photo-triac optocoupler
• Output Type: AC triac switching for resistive and inductive loads
• Zero-Crossing: Triac switching reduces EMI and electrical noise
• Isolation Type: Galvanic isolation between DC control and AC load circuits

Standards and Compliance

• Industrial Standards: Designed for industrial automation applications
• Safety Standards: Galvanic isolation for electrical safety
• Quality Standards: Murrelektronik industrial quality and reliability
• DIN Rail Standards: Standard DIN rail mounting compatibility
• Environmental Standards: Industrial environmental protection ratings

Applications

• DC control of AC motors and actuators
• Industrial lighting control from DC systems
• AC heating element control and regulation
• Process control equipment AC switching
• DC PLC output to AC load interface applications
• Compact control cabinet AC switching solutions

Installation Features

• Ultra-Compact Design: 6.2mm width maximizes control cabinet space utilization
• DIN Rail Mounting: Standard industrial mounting capability
• Screw Terminals: Secure and reliable wiring connections
• DC-to-AC Interface: Seamless interface between DC control and AC loads
• Professional Integration: Standard industrial module format

Space-Saving Benefits

• Maximum Density: 6.2mm width allows high-density installations
• Cabinet Efficiency: Optimized for space-constrained control panels
• High Performance: 1A switching capability in minimal footprint
• Flexible Layout: Compact design enables versatile panel arrangements
• Cost Efficiency: Reduced panel space requirements lower installation costs

Benefits

• Enables reliable DC control of AC loads up to 1A with complete galvanic isolation
• Provides ultra-compact 6.2mm width design for maximum control cabinet space efficiency
• Features zero-crossing triac switching technology to minimize electrical interference
• Offers versatile 53VDC input range for compatibility with various DC control systems
• Supports high-density installations with secure screw terminals and professional-grade construction

Download existing graphical data for this product:

• Product Specification Sheet
