Murr M8 male 0°/ M12 female 0°, 3-pole, black, 3m

Product Overview

M8 to M12 sensor-actuator connection cable (SKU: 7000-88241-6100300) designed for extending sensor and actuator connections in industrial automation systems. This 3-pole A-coded connection cable features gold-plated contacts and PVC construction with UL/CSA certification for reliable signal transmission in standard industrial environments.

Key Features

• M8 male straight (0°) to M12 female straight (0°) A-coded configuration
• 3-pole connection with gold-plated copper alloy contacts
• 3m black PVC cable for cost-effective industrial applications
• UL/CSA certified (cURus) construction
• Zinc die-casting housing with nickel-plated coating
• Vibration protection through union nut design
• IP65/IP67/IP68/IP66K protection ratings when properly mated
• Lead-free, cadmium-free, CFC-free, silicone-free construction

Technical Specifications

• Connector 1: M8 male straight (0°) A-coded, M8x1 thread, SW9
• Connector 2: M12 female straight (0°) A-coded, M12x1 thread, SW13
• Pole Count: 3-pole
• Cable Length: 3m
• Operating Voltage: 50V AC max, 60V DC max
• Current Rating: 4A max per contact
• Wire Cross-section: 0.25mm² stranded copper (Class 5)
• Cable Type: PVC jacket, black color
• Operating Temperature: -30°C to +85°C
• Protection Rating: IP65/IP67/IP68/IP66K

Applications

• Sensor signal extension in standard industrial automation
• Actuator connection extensions for machinery applications
• Process control device connections in indoor environments
• Factory automation signal transmission
• Machine control signal routing in temperature-controlled areas
• Industrial sensor networks requiring cost-effective solutions
• Equipment interfacing in protected industrial environments

Compliance & Standards

• UL/CSA certified (cURus) construction
• DIN EN 61076-2-101 (M12) and DIN EN 61076-2-114 (M8) compliant
• Chemical, oil, and gasoline resistant
• UV resistant per DIN EN ISO 4892-2 A
• Flame resistant per UL 1581 and IEC 60332-2-2
• Environmental and safety compliant materials
