Description
xThis differential thermal overload relay ensures motor protection with adjustable settings between 48A and 65A. It includes a trip indicator and is compatible with LC1E65...95 contactors, offering robust protection for industrial-grade motors.
Specifications
x| IP Rating | IP20 |
| Compliance/Certifications | EAC / IEC 60947-4-1 / IEC 60947-5-1 |
| Temperature: Operating | France |
| Temperature: Operating | -20°C to 60 °C / -20°C to 70 °C |
| Part Depth (mm) | 113 mm |
| Part Width (mm) | 70 mm |
| Part Height (mm) | 54 mm |
| Weight (g) | 460 g |
| Packaging size / unit | 1 / 9 pc(s) |
| Tightening Torque | 1.7 Nm / 9 Nm |
| Connection Type | Power circuit: screw clamp terminals 1 4-35 mm² - cable stiffness: flexible with cable end / Power circuit: screw clamp terminals 1 4-35 mm² - cable stiffness: flexible without cable end / Power circuit: screw clamp terminals 1 4-35 mm² - cable stiffness: solid without cable end / Signalling circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: flexible with cable end / Signalling circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: flexible without cable end / Signalling circuit: screw clamp terminals 2 1-2.5 mm² - cable stiffness: solid without cable end |
| Rated Operating Voltage | <= 690 V AC |
