Description
xThis pushbutton with a green illuminated head is designed for high visibility and dependable use in industrial control panels.
Specifications
x| IP Rating | IP20 / IP65 |
| Compliance/Certifications | CCC / GB 14048.1 / GB 14048.5 / IEC 60947-1 / IEC 60947-5-1 |
| Temperature: Operating | -25 °C to 70 °C |
| Part Depth (mm) | 53mm |
| Part Width (mm) | 29mm |
| Part Height (mm) | 29mm |
| Weight (g) | 17g |
| Screw Type | Cross compatible with JIS No 1 screwdriver / Cross compatible with Philips no 1 screwdriver / Cross compatible with pozidriv No 1 screwdriver / Slotted compatible with flat Ø 4 mm screwdriver / Slotted compatible with flat Ø 5.5 mm screwdriver |
| Connection Type | Screw clamp terminals / <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1 / Screw clamp terminals / 1 x 0.5 - 1 x 2.5 mm² without cable end conforming to EN/IEC 60947-1 |
| Supply Voltage | 24 VAC/DC 50/60 Hz |
| Current Consumption | 20 - 27 mA |
| Warranty | 18 Months |
| Colour | Blue |
