Description
xThis pilot light with a red LED is suitable for industrial control applications, ensuring reliable operation and easy identification. It has a 22 mm mounting diameter and complies with IEC 60947-5-1 standards.
Specifications
x| IP Rating | IP66 / IP67 / IP69 / IP69K |
| Compliance/Certifications | BV / CSA / CSA C22.2 No 14 / DNV / GL / IEC 60947-1 / IEC 60947-5-1 / IEC 60947-5-4 / IEC 60947-5-5 / JIS C8201-1 |
| Temperature: Operating | -40°C to 70 °C |
| Part Depth (mm) | 101mm |
| Part Width (mm) | 30mm |
| Part Height (mm) | 47mm |
| Weight (g) | 97g |
| Packaging size / unit | 1 / 50 pc(s) |
| Tightening Torque | 0.8 - 1.2 Nm |
| Material: Product | Silver alloy (Ag/Ni) |
| Screw Type | Cross compatible with Philips no 1 screwdriver / Cross compatible with pozidriv No 1 screwdriver / Slotted compatible with flat Ø 4 mm screwdriver / Slotted compatible with flat Ø 5.5 mm screwdriver |
| Communication | 1 NO + 1 NC |
| Connection Type | Screw clamp terminals / <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1 / Screw clamp terminals / 1 x 0.22 - 2 x 2.5 mm² without cable end conforming to IEC 60947-1 |
| Supply Voltage | 230 - 240 VAC at 50/60 Hz |
| Current Consumption | 14 mA |
| Operating Period | 10000000 cycles (mechanical) / 1000000 cycles / AC-15 / 2 A at 230 V / operating rate <3600 cyc/h / load factor: 0.5 conforming to IEC 60947-5-1 appendix C / 1000000 cycles / AC-15 / 3 A at 120 V / operating rate <3600 cyc/h / load factor: 0.5 conforming to IEC 60947-5-1 appendix C / 1000000 cycles / AC-15 / 4 A at 24 V / operating rate <3600 cyc/h / load factor: 0.5 conforming to IEC 60947-5-1 appendix C / 1000000 cycles / DC-13 / 0.2 A at 110 V / operating rate <3600 cyc/h / load factor: 0.5 conforming to IEC 60947-5-1 appendix C / 1000000 cycles / DC-13 / 0.5 A at 24 V / operating rate <3600 cyc/h / load factor: 0.5 conforming to IEC 60947-5-1 appendix C (electrical) |
| Warranty | 12 Months |
