Description
xThis emergency stop switch disconnector provides enhanced safety with IP65 protection and robust construction for industrial environments. It supports AC and DC networks and includes a padlockable rotary handle.
Specifications
x| IP Rating | IP65 |
| Compliance/Certifications | IEC 60204 / IEC 60947-4-1 |
| Temperature: Operating | -20°C to 50 °C |
| Part Depth (mm) | 131mm |
| Part Width (mm) | 90mm |
| Part Height (mm) | 146mm |
| Weight (g) | 500g |
| Packaging size / unit | 1 / 7 / 56 pc(s) |
| Tightening Torque | 2.1 Nm |
| Connection Type | Screw clamp terminals10 mm² - solid / Screw clamp terminals6 mm² - flexible - with cable end |
| Rated Operating Voltage | 690 VAC |
| Operating Period | 100000 cycles (mechanical) / 100000 cycles AC-21 / 30000 cycles DC-1 - 5 (electrical) |
| Warranty | 18 Months |
| Colour | Red |
