Description
xThis thermal overload relay offers protection for motors in the range of 0.6–1 A. It is designed for easy installation on contactors and provides reliable operation under varied conditions, ensuring motor safety and performance.
Specifications
x| IP Rating | IP2X |
| Compliance/Certifications | BS 4941 / CSA / IEC 60947 / NF C 63-650 / UKCA / UL / VDE 0660 |
| Temperature: Operating | -20 °C to 55 °C |
| Part Depth (mm) | 65mm |
| Part Width (mm) | 45mm |
| Part Height (mm) | 58mm |
| Weight (g) | 145g |
| Tightening Torque | 1.3 Nm |
| Connection Type | Screw clamp terminals 1 cable(s) 1.5 - 4 mm²solid / Screw clamp terminals 2 cable(s) 1.5 - 4 mm²solid / Screw clamp terminals 1 cable(s) 0.75 - 4 mm²flexible without cable end / Screw clamp terminals 2 cable(s) 0.75 - 4 mm²flexible without cable end / Screw clamp terminals 1 cable(s) 0.34 - 2.5 mm²flexible with cable end / Screw clamp terminals 2 cable(s) 0.34 - 1.5 mm²flexible with cable end |
| Max Frequency | <= 400 Hz |
| Type of Voltage | DC / AC |
| Rated Operating Voltage | <= 690 V for power circuit |
| Mounting Type | Plate / with specific accessories / Rail / with specific accessories / Under contactor |
| Warranty | 18 Months |
