Rittal KX Terminal box, sheet steel, 500 x 300 x 120mm Rittal
Rittal KX Terminal box, sheet steel, 500 x 300 x 120mm Rittal

Rittal KX Terminal box, sheet steel, 500 x 300 x 120mm Part number 1509.000

The small enclosure KX, terminal box KX, without a gland plate allows for flexible interior installation while maintaining a high protection category.
Vendor: Rittal
Rubicon Industrial Technology is an authorised South African distributor for Rittal.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x
The small enclosure KX, terminal box KX, without a gland plate allows for flexible interior installation while maintaining a high protection category.
Specifications
Specifications
x
Model NumberKX 1509.000
MaterialHousing: Carbon steel; Cover: Carbon steel, all-round foamed-in PU seal
Surface FinishDipcoat primed, powder-coated on the outside, textured paint
ColorRAL 7035
Protection Category NEMANEMA 1, NEMA 3R, NEMA 4, NEMA 12
Protection Category IP to EN 60 529IP 66
Type Rating according to UL 50EType 1, Type 3R, Type 4, Type 12
IK CodeIK08
Dimensions (Width x Height x Depth)500 mm x 300 mm x 120 mm (19.7 in x 11.8 in x 4.72 in)
Material Thickness - Cover1.25 mm (0.05 in)
Material Thickness - Enclosure1.25 mm (0.05 in)
Base MaterialCarbon steel
Weight5.57 kg (12.3 lb)
Documents
Documents
x
Download Datasheet
